Engine Instruments (Fl 20000 - 20999)
RPM Gauges (Tachometers) - Drehzahlmesser
|
Title |
Aircraft Used In | Range | FL Number | Thumbnail | For Sale |
| RPM Gauge (Deuta) | 600 - 1800 RPM | FL 20205 |  |
||
| RPM Gauge (Deuta) | He46, JuW34 |
600 - 2400 RPM | FL 20206 |  |
|
| RPM Gauge | Ar96, Klem KL35, L25, Si 202, |
600 - 3000 RPM | FL 20207 | ||
| RPM Gauge | Bu133 |
600 - 3600 RPM | FL 20210 | ||
| RPM Gauge | Ar79, FW44, He72 |
500 - 2400 RPM | FL 20212 |  |
|
| RPM Gauge | Bu133 |
600 - 3600 RPM | FL 20213 | ||
| RPM Gauge | Ar79, Ju52 |
500 - 2400 RPM | FL 20218 | ||
| Mechanical RPM Gauge | Bf108 B1, |
600 - 3000 RPM | FL 20219 | ||
| RPM Gauge | Bf109B, Bu131, Ju87 A |
600 - 3600 RPM | FL 20220 | ||
| RPM Gauge | Bf108D, Fw190A1-4, Bf109E |
600 - 3600 RPM | FL 20222-2 | ||
| RPM Gauge | Ar79, AR96, Bu181, Fi156C, FW190A7-9 |
600 - 3600 RPM | FL 20222-3 |  |
|
| Mechanical RPM Gauge | Do335 |
500 - 3600 RPM | FL 20227 |  |
|
| Unknown (Winkelgetriebe) | N/A | FL 20243 |  |
||
| Electric RPM Gauge | BA349 M24, Me163, Ta152 H-0, |
0 - 12,500 RPM | FL 20265 |  |
|
| RPM Gauge | Ar234 B-2, Go229, He162, ME163 |
2000-15,000 RPM | FL 20266 | ||
| Combined RPM & Boost Gauge | Bu155, Do335, FW190D-9, He219, Ju388 |
500 - 3600 RPM | FL 20269 |  |
|
| Double RPM Gauge | Ju88G1 |
2X 500-3600 RPM | FL 20270 | ||
| Double RPM Gauge | Do335 |
2X 500-3600 RPM | FL 20274 | ||
| RPM Gauge | Ju52 |
0 - 2400 RPM | FL 20276 | ||
| Electric RPM Gauge | He111C |
0 - 1800 RPM | FL 20282 | ||
| Electric RPM Gauge | Do24 |
400 - 2400 RPM | FL 20283 | ||
| RPM Gauge | He111D,P & H, Ju88A1 |
500 - 3000 RPM | FL 20284 | ||
| Remote Read RPM Gauge | Bf110C, Ju52 mg14e |
500 - 3600 RPM | FL 20286 |  |
Temperature Gauges - Temperaturanzeiger
|
Title |
Aircraft Used In |
Range | FL Number | Thumbnail | No. For Sale |
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20303 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20306 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20307 | |||
| Oil Temperature Gauge | Ar79, FW44, JuW34, Ar96 |
0 - 160 oC | FL 20308 | ||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20308 | |||
| Oil Temperature Gauge (2 Meter capillary) | He46, Ju52, Bf108B-1 + D, He111E+F |
0 - 120 oC | FL 20308-2 | ||
| Temperature Guage (3 Meter capillary) | 0 - 160 oC | FL 20308-3 | |||
| Coolant Temperature Gauge (4 Meter capillary) | Ju87A & B |
0 - 120 oC | FL 20308-4 | ||
| Vapour Temperature Gauge (2 Meter capillary) | Ju87A |
0 - 160 oC | FL 20308-6 |  |
|
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20309 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20310 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20311 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20312 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20313 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20314 | |||
| Vapour Temperature Gauge | Bu133 |
0 - 160 oC | FL 20314-2 | ||
| Coolant Temperature Gauge | Bf109B |
30 - 120 oC | FL 20314-4 | ||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20315 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20316 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20317 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20318 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20320 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20321 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20322 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20323 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20324 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20325 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20326 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20328 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20329 | |||
| Double Oil Temperature Gauge | Fi156C, Ju87B |
0 - 120 oC | FL 20330 | ||
| Double Temperature Gauge (10 Meter Capillary) | 0 - 120 oC | FL 20330-10 | |||
| Double Temperature Gauge (12 Meter Capillary) | 0 - 120 oC | FL 20330-12 | |||
| Double Temperature Guage (2 Meter Capillary) | 0 - 120 oC | FL 20330-2 | |||
| Double Oil Temperature (4 Meter Capillary) | Bf109B |
0 - 120 oC | FL 20330-4 | ||
| Double Temperature Guage (6 Meter Capillary) | 0 - 120 oC | FL 20330-6 | |||
| Double Oil Temperature Gauge (8 Meter Capillary) | He111E+F, Ju88C-6 |
0 - 120 oC | FL 20330-8 | ||
| Double Coolant Temperature Gauge | He111C |
30 - 180 oC | FL 20331 | ||
| Double Pressure driven Temperature Guage (2 meter capillary) | 0 - 160 oC | FL 20331-2 | |||
| Double Pressure driven Temperature Guage (2 meter capillary) | 0 - 160 oC | FL 20331-3 | |||
| Double Pressure driven Temperature Guage (2 meter capillary) | 0 - 160 oC | FL 20331-4 | |||
| Double Pressure driven Temperature Guage (2 meter capillary) | 0 - 160 oC | FL 20331-6 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20332 | |||
| Temperature Gauge (Pressure Driven) | Ar66, Ar79 |
0 - 120 oC | FL 20335 | ||
| Pressure Driven Temperature Gauge (1 meter capillary) | 0 - 120 oC | FL 20335-1 | |||
| Pressure Driven Temperature Gauge (2 meter capillary) | 0 - 120 oC | FL 20335-2 | |||
| Pressure Driven Temperature Gauge (3 meter capillary) | 0 - 120 oC | FL 20335-3 | |||
| Pressure Driven Temperature Gauge (4 meter capillary) | 0 - 120 oC | FL 20335-4 | |||
| Pressure Driven Temperature Gauge (6 meter capillary) | 0 - 120 oC | FL 20335-6 | |||
| Temperature Gauge (Pressure Driven) | 40 - 160 oC | FL 20336 | |||
| Pressure Driven Temperature Gauge (1 Meter Capillary) | 40 - 160 oC | FL 20336-1 | |||
| Pressure Driven Temperature Gauge (2 Meter Capillary) | 40 - 160 oC | FL 20336-2 | |||
| Pressure Driven Temperature Gauge (3 Meter Capillary) | 40 - 160 oC | FL 20336-3 | |||
| Pressure Driven Temperature Gauge (4 Meter Capillary) | 40 - 160 oC | FL 20336-4 | |||
| Pressure Driven Temperature Gauge (6 Meter Capillary) | 40 - 160 oC | FL 20336-6 | |||
| Temperature Sensor - Temperaturgeber | N/A | FL 20337 | |||
| Jet Pipe Temperature Gauge | Ar234, He162, Me163, Me262 |
300 - 1000 oC | FL 20338 |  |
|
| Electric Temperature Sensor - Temperaturgeber | N/A | FL 20340 | |||
| Outside Air temperature sensor - connects to FL 20342-1 | N/A | FL 20341 |  |
||
| Radiator Temperature Gauge | Do24, Fi156C, He219, Ju87D, Ju88G1, Fw190 A7-9, |
0 - 130 oC | FL 20342 |  |
|
| Outside Air Temperature | Do24, He111E,F,D,P,H1,H2 & H20, Ju88, Bf110 |
-60 / +40 oC | FL 20342-1 | ||
| Oil Temperature Gauge | Ar96, Fi156c, Fw190A1-4, He111D,P,H1&H2, Ju87B-2, Ju88 |
0 - 120 oC | FL 20342-2 | ||
| Coolant Temperature Gauge | Bf109C,D & E, Bf110 |
40 - 120 oC | FL 20342-3 | ||
| Electric Temperature Gauge | Fi156c, He111D,P,H1,H2 & H20, Ju87B-2, Bf109C,D,E & F |
0 - 160 oC | FL 20343 |  |
|
| Outside & intake Air Temperature | Ju52, Ar234, Do24, Go229, Ju88c-6, Ju388, Me262 |
-60 / +40 oC | FL 20349 |  |
|
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20350 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20351 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20352 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20353 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20354 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20355 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20356 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20357 | |||
| Oil Temperature Gauge | Bv155, Do355, Ju388, Bf109K |
0 - 130 oC | FL 20358 |  |
|
| Electric Quad Temperature Gauge | Do24 |
0 - 160 oC | FL 20360 | ||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20365 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20366 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20367 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20368 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20369 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20370 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20371 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20372 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20373 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20374 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20375 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20376 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20377 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20378 | |||
| Temperature Gauge (Pressure Driven) | 0 - 160 oC | FL 20379 | |||
| Oil Temperature Gauge | Fw190D-9, Ta152 H-0, |
0 - 130 oC | FL 20385 | ||
| Outside Air Temperature | He111C |
-40 / +40 oC | FL 20400 |
Pressure Gauges - Druckmesser
|
Title |
Aircraft Used In | Range | FL Number | Thumbnail | No. For Sale |
| Cockpit Pressure Gauge | BV155, Ta152, Ju388, Me262 |
0-15 km / 0 - 0.6 atm | FL 20325 | ||
| Suction Pressure | Do24T |
0-3 Kg/cm2 | FL 20471 | ||
| Fuel Pressure Gauge | Ar66, Fw44, Fw190D-9, He111, Bf109K, Klem KL35 |
0-0.5 Kg/cm2 | FL 20504 | ||
| Fuel Pressure Gauge | Ar79, Bu131, Bu153, He46, He72, Ju234, Klem L35 |
0-1 Kg/cm2 | FL 20504-1 | ||
| Pressure Gauge |
|
0-3 Kg/cm2 | FL 20504-3 |  |
|
| Pressure Gauge | He162 |
0-10 Kg/cm2 | FL 20504-10 |  |
|
| Fuel Pressure Gauge | Ar66, Bu133, He46, He72, JuW34, Ju52, Klem L25D, Klem L35, He111, Bf109 |
0-0.5 Kg/cm2 | FL 20505 | ||
| Double Wheel Brake Pressure | Ju52 |
0-2 & 0-200 Kg/cm2 | FL 20511 | ||
| Double fuel & oil pressure gauge | Bf108 B1 + D, Ar96, Erla 5D |
0-0.5 & 0-10 Kg/cm2 | FL 20512 |  |
|
| Double fuel & oil pressure gauge | Bf108 B1, Ar96, Bu181, Bu133, Fi156 |
0-2 & 0-10 Kg/cm2 | FL 20512-1 | ||
| Double fuel & oil pressure gauge | Erla 5D, Ju52, Fw190, Ju87D, Bf109 |
0-1 & 0-10 Kg/cm2 | FL 20512-2 |  |
|
| Double fuel & oil pressure gauge | Bu155, FW190, Ta152 H-0, |
0-3 & 0-15 Kg/cm2 | FL 20512-3 |  |
|
| Double Pressure Gauge | Ta152 H, |
FL 20512-6 | |||
| Pressure Gauge |
|
0-200 Kg/cm2 | FL 20513-4 | ||
| Differential Pressure Gauge | He162, Me262 |
0-1 Kg/cm2 | FL 20515 | ||
| Hydraulic Pressure Gauge | Ju87D |
0-120 Kg/cm2 | FL 20516-1 | ||
| Fuel Pressure | He162, Me262 |
0-160 Kg/cm2 | FL 20516-2 |  |
|
| Ejection & Hydraulic Pressure Gauge | Ar234, Do335, Go229, Ju88, Ju388, Me163, Me262 |
0-160 Kg/cm2 | FL 20516-3 |  |
|
| Compressed Air Pressure | Ta152 H-0, |
FL 20516-4 | |||
| Compressed Air Pressure Gauge | Bf108 B1 + D, Do355, Go229, Bf110, Me163 |
0-250 Kg/cm2 | FL 20519 | ||
| Jet Turbine / Chamber Pressure | M24 Prototype, Ba349 |
0-25 Kg/cm2 | FL 20521 | ||
| Pressure Gauge |
|
0-160 Kg/cm2 | FL 20526-3 |  |
|
| Boost Pressure Gauge | He46D, JuW34, Ar96, He11E/F Ju87, Bf109, Bf110 |
0.6 - 1.8 atm | FL 20550 | ||
| Pressure Gauge |
|
200 - 2500 mmWs | FL 20552 |  |
|
| Suction Pressure Gauge | Ju52 |
0.2 - 2 atm / 200 - 2000 mmWs | FL 20553 | ||
| Boost Pressure Gauge | Fw190 D-9, |
0.5 - 2.5 atm | FL 20554 |  |
|
| Boost Pressure Gauge | Ju87, FW190 A1-4, Bv155, Do24, Ta152 H-0, Ju88, Bf109F&K, Bf110 |
0.6 - 1.8 atm | FL 20555 |  |
|
| Double Boost Pressure Gauge | Ar234 B-2, Do335, He219 |
2 x 0.6 - 1.8 atm | FL 20556 | ||
| Electric Quad fuel & Oil pressure gauge | Do24 |
3 x 0-10 / 1 x 0-0.5 Kg/cm2 | FL 20560 | ||
| Combined RPM & Boost Pressure gauge | Do335, Go229, Ju388, Ta152 H, |
500 - 3600 rpm / 0.6 - 1.8 atm | FL 20569 | ||
| Fuel & Oil pressure gauge | Do355, He219 |
0-10 Kg/cm2 | FL 20572 |  |
|
| Fuel Pressure | Do335, Ju388 |
0-3 Kg/cm2 | FL 20582 | ||
| Oil Pressure | Do335 |
0-15 Kg/cm2 | FL 20584 | ||
| SUM AP8 Starter injection pump | Klem L25D |
N/A | FL 20592 | ||
| Oil Pressure |
|
0-10 Kg/cm2 | FL 20604-3 |  |
|
| Oil Pressure | Ar66, Fw44, He46, He72, JuW34, Bf109 |
0-10 Kg/cm2 | FL 20606 | ||
| Oil Pressure | Ju52, He111, Ju52 (As fire extinguisher pressure) |
0-10 Kg/cm2 | FL 20625 | ||
| Electric Quad fuel & Oil pressure gauge |
|
2 x 0-1 & 0-10 Kg/cm2 | FL 20682 |  |
Fuel Content and Flow gauges.
It is important to note that many fuel gauges have the same part number but read to a wide and varied range. For instance ten examples were found for the fuel gauge FL 20723 all reading to different values
|
Title |
Aircraft Used In | Range | FL Number | Thumbnail | No. For Sale |
| Fuel Contents Gauge | Bu133 (Mounted in the cowling) |
FL 20703-2 | |||
| Fuel Contents Gauge | Bu181 |
0 - 100L | FL 20704 | ||
| Fuel Contents Gauge | Ar79, He46, JuW34, Klem KL35, BF108, Ar96 |
0 - 150L / 0-120L | FL 20704 | ||
| Fuel Contents Gauge | Ju87 A |
0 - 220 L | FL 20704 | ||
| Fuel Contents Gauge | Ju87 D |
0 - 250 L | FL 20704 | ||
| Fuel Contents Gauge | Bf109 B |
0 - 340 L | FL 20704 | ||
| Fuel Contents Gauge | Ju52 / 3m |
0 - 1260 L | FL 20709 |  |
|
| Fuel Contents Gauge | He111 E + F |
0 - 700 L | FL 20710 | ||
| Fuel Contents Gauge | Fi156C, |
FL 20712 | |||
| Fuel Contents Gauge | Ar96 |
0 - 175 L | FL 20723 | ||
| Fuel Contents Gauge | 0 - 230 L | FL 20723 |  |
||
| Fuel Contents Gauge | Fw190, Ta152 |
0 - 300 / 0 - 230 L | FL 20723 |  |
|
| Fuel Contents Gauge | Bf110C, Ar96 |
0 - 380 / 0 - 270 L | FL 20723 |  |
|
| Fuel Contents Gauge | Bf109C + D |
0 - 410 L | FL 20723 |  |
|
| Fuel Contents Gauge | Me262 |
0 - 610 L | FL 20723 | ||
| Fuel Contents Gauge | Bv155, He162A |
0 - 700 L | FL 20723 | ||
| Fuel Contents Gauge | He219 |
0 - 700 / 0 - 1025 L | FL 20723 | ||
| Fuel Contents Gauge | Ar234 |
0 - 1800 L | FL 20723 | ||
| Fuel Contents Gauge | Do355 |
0 - 1200 L | FL 20723 | ||
| Fuel Contents Gauge | Ju88 A-1, A-16 & C6 |
0 - 1200 / 0 - 420 L | FL 20723 | ||
| Fuel Contents Gauge | Ar234 |
0 - 2000 L | FL 20723 | ||
| Fuel Contents Gauge | Me262 |
0 - 9000 L | FL 20723 |  |
|
| Fuel Contents Gauge | 0 - 2000 L | FL 20723 |  |
||
| Fuel Gauge Air Pump | Ar66, Bu181, |
N/A | FL 20742 | ||
| Fuel contents gauge selector switch | Bf108 B1, |
N/A | FL 20754-2 | ||
| Fuel Flow Meter | Ju52 |
80 - 180 L/H | FL 20772 |
Propeller pitch indicators
|
Title |
Aircraft Used In | Range | FL Number | Thumbnail | No. For Sale |
| ? | 1000 - 5000 | FL 20812 |  |
||
| Propeller pitch indicator | Bv155 V2, Do 24, Do24 T, |
FL 20841 | |||
| Propeller pitch indicator | Do335, Ta152 H, |
FL 20845 |
